Model 192 Current Transformer
Introducing the Model 192 Current Transformer, a high-quality electrical measurement device, distributed by Spectrum Industries. Designed for precision and reliability, this current transformer is an essential tool for professionals in electrical testing, power distribution, and industrial automation. Its robust construction and advanced features ensure accurate current measurement across a wide range of applications, making it an invaluable asset for engineers and technicians alike.
Overview
Introducing the Model 192 Current Transformer, a high-quality electrical measurement device, distributed by Spectrum Industries. Designed for precision and reliability, this current transformer is an essential tool for professionals in electrical testing, power distribution, and industrial automation. Its robust construction and advanced features ensure accurate current measurement across a wide range of applications, making it an invaluable asset for engineers and technicians alike.
The Model 192 Current Transformer is engineered to deliver consistent performance even in demanding environments. Its design emphasizes safety, durability, and ease of installation, allowing users to obtain precise readings without compromising operational efficiency. Whether used for monitoring electrical systems, performing maintenance, or conducting detailed analysis, this transformer provides dependable data that supports informed decision-making and system optimization.
a globally recognized leader in electrical equipment and technology, the Model 192 benefits from decades of innovation and expertise. Spectrum Industries proudly offers this product, ensuring it meets the highest standards of quality and performance. With its user-friendly features and exceptional accuracy, the Model 192 Current Transformer is an excellent choice for professionals seeking a trusted solution for their current measurement needs. Trust in ’s legacy of excellence combined with Spectrum Industries’ commitment to quality to enhance your electrical measurement capabilities.
Request a Quote for Model 192 Current Transformer
Product Specifications
- Frequency
- 50–400 Hz
- Insulation BIL
- 10 kV
- Weight
- 4.75 lbs
- Application
- Metering, Protection
- Standards
- ANSI/IEEE C57.13, IEC 44-1
- Window diameter
- 1.75"
- Rated insulation voltage
- 600 Volts
- Terminals
- Brass studs No. 8-32 with one flatwasher, lockwasher and regular nut
- Mounting bracket kit
- 0221B00777
- Multi-ratio availability
- Multi-ratios available on request
- Regulatory approval
- Industry Canada Approval No. T-195
Specification Table
| Primary A | Secondary A | Ratio (display) | Relay Class | ANSI Metering Class | Thermal Rating Factor @ 30°C | Thermal Rating Factor @ 55°C | Secondary Resistance |
|---|---|---|---|---|---|---|---|
| 100 | 5 | 100:5 | — | 0.6B0.1 | 2 | 2 | 0.031 |
| 150 | 5 | 150:5 | — | 0.6B0.2 | 2 | 2 | 0.058 |
| 200 | 5 | 200:5 | C10 | 0.3B0.2 | 2 | 1.5 | 0.063 |
| 250 | 5 | 250:5 | C10 | 0.3B0.5 | 2 | 1.5 | 0.097 |
| 300 | 5 | 300:5 | C10 | 0.3B0.5 | 2 | 1.33 | 0.131 |
| 400 | 5 | 400:5 | C20 | 0.3B0.9 | 1.5 | 1 | 0.174 |
| 500 | 5 | 500:5 | C20 | 0.3B0.9 | 1.5 | 1 | 0.218 |
