Model 195 Current Transformer
Introducing the Model 195 Current Transformer, a high-quality electrical component and brought to you by Spectrum Industries. Designed with precision and reliability in mind, this current transformer is an essential tool for accurate current measurement and monitoring in various electrical systems. Whether you're involved in industrial automation, power distribution, or maintenance, the Model 195 offers the performance and durability you need to ensure your operations run smoothly.
Overview
Introducing the Model 195 Current Transformer, a high-quality electrical component and brought to you by Spectrum Industries. Designed with precision and reliability in mind, this current transformer is an essential tool for accurate current measurement and monitoring in various electrical systems. Whether you're involved in industrial automation, power distribution, or maintenance, the Model 195 offers the performance and durability you need to ensure your operations run smoothly.
a global leader in electrical and electronic manufacturing, this current transformer benefits from decades of expertise and innovation. Its robust construction ensures consistent performance even in demanding environments, making it suitable for both commercial and industrial applications. The Model 195 features a compact design that facilitates easy installation and integration into existing systems, helping to streamline your electrical infrastructure.
Spectrum Industries, a trusted distributor of high-quality electrical components, offers the Model 195 Current Transformer to meet the needs of professionals seeking dependable and precise measurement solutions. With its excellent accuracy, safety features, and durable build, this transformer is an excellent choice for those looking to enhance their electrical systems' efficiency and safety. Invest in the Model 195 from Spectrum Industries and experience the reliability and performance that is renowned for in the electrical industry.
Request a Quote for Model 195 Current Transformer
Product Specifications
- Frequency
- 50–400 Hz
- Insulation BIL
- 10 kV
- Weight
- 2.25 lbs
- Application
- Metering, Protection
- Standards
- UL, ANSI/IEEE C57.13, IEC 44-1
- Window Diameter
- 3.06 in
- Insulation Level
- 600 V, 10 kV BIL full wave
- Terminal Description
- Brass studs No. 8-32 with one flatwasher, lockwasher and regular nut
- Mounting Bracket Kit
- 0221B00777 (order separately)
- Multi-Ratio Availability
- Available on request
Specification Table
| Primary A | Secondary A | Ratio (display) | ANSI Metering Class | Thermal Rating Factor @ 30°C | Thermal Rating Factor @ 55°C | Secondary Resistance |
|---|---|---|---|---|---|---|
| 200 | 5 | 200:5 | 0.6B0.1 | 2 | 2 | 0.04 |
| 250 | 5 | 250:5 | 0.3B0.1 | 2 | 2 | 0.069 |
| 300 | 5 | 300:5 | 0.3B0.1 | 2 | 2 | 0.068 |
| 400 | 5 | 400:5 | 0.3B0.2 | 2 | 1.5 | 0.11 |
| 500 | 5 | 500:5 | 0.3B0.5 | 2 | 1.5 | 0.105 |
| 600 | 5 | 600:5 | 0.3B0.5 | 1.5 | 1.33 | 0.151 |
| 750 | 5 | 750:5 | 0.3B0.5 | 1.5 | 1 | 0.197 |
| 800 | 5 | 800:5 | 0.3B0.5 | 1 | 0.8 | 0.265 |
| 1000 | 5 | 1000:5 | 0.3B0.5 | 1 | 0.8 | 0.209 |
| 1200 | 5 | 1200:5 | 0.3B0.9 | 1 | 0.6 | 0.301 |
