Model 24 Current Transformer
Introducing the Model 24 Current Transformer, a reliable and high-performance instrument and distributed by Spectrum Industries. Designed to meet the demanding needs of electrical professionals, this current transformer offers precise measurement and monitoring capabilities essential for a wide range of industrial and commercial applications. Whether used for power distribution, system analysis, or protective relaying, the Model 24 ensures accurate current readings, contributing to the safety and efficiency of electrical systems.
Overview
Introducing the Model 24 Current Transformer, a reliable and high-performance instrument and distributed by Spectrum Industries. Designed to meet the demanding needs of electrical professionals, this current transformer offers precise measurement and monitoring capabilities essential for a wide range of industrial and commercial applications. Whether used for power distribution, system analysis, or protective relaying, the Model 24 ensures accurate current readings, contributing to the safety and efficiency of electrical systems.
a global leader in electrical equipment and technology, this current transformer embodies durability and precision. Its robust construction is engineered to withstand harsh environments, providing long-lasting performance even under demanding conditions. The Model 24 features a compact design that facilitates easy installation and integration into existing electrical setups, making it a versatile choice for technicians and engineers alike.
Spectrum Industries, a trusted distributor of electrical instrumentation, offers this product to ensure customers have access to top-quality equipment backed by reputable manufacturers. The Model 24 Current Transformer is an essential tool for those seeking accurate current measurement solutions that combine reliability, ease of use, and durability. With ’s legacy of innovation and Spectrum Industries’ commitment to customer satisfaction, this product stands out as a dependable component for your electrical measurement needs.
Request a Quote for Model 24 Current Transformer
Product Specifications
- Frequency
- 50–400 Hz
- Insulation BIL
- 10 kV
- Weight
- 6.5 lbs
- Application
- Metering, Protection
- Standards
- UL, ANSI/IEEE C57.13, IEC 44-1
- Window Diameter
- 2.50 in
- Rated Insulation Voltage
- 600 Volts
- Terminals
- Brass studs No. 8-32 with one flatwasher, lockwasher and regular nut
- Mounting Bracket Kit
- 0221B00541 (order separately)
- Ratio Availability
- Multi-ratios available upon request
Specification Table
| Primary A | Secondary A | Ratio (display) | Relay Class | ANSI Metering Class | Thermal Rating Factor @ 30°C | Thermal Rating Factor @ 55°C | Secondary Resistance |
|---|---|---|---|---|---|---|---|
| 100 | 5 | 100:5 | — | 0.6B0.1 | 2 | 2 | 0.046 |
| 150 | 5 | 150:5 | — | 0.6B0.2 | 2 | 2 | 0.069 |
| 200 | 5 | 200:5 | C10 | 0.3B0.2 | 2 | 1.5 | 0.096 |
| 250 | 5 | 250:5 | C10 | 0.3B0.5 | 2 | 1.5 | 0.118 |
| 300 | 5 | 300:5 | C10 | 0.3B0.5 | 2 | 1.5 | 0.133 |
| 400 | 5 | 400:5 | C20 | 0.3B0.5 | 1.5 | 1 | 0.212 |
| 500 | 5 | 500:5 | C20 | 0.3B0.9 | 1.5 | 1 | 0.265 |
| 600 | 5 | 600:5 | C20 | 0.3B1.8 | 1.33 | 1 | 0.317 |
