Model 298 Current Transformer
Introducing the Model 298 Current Transformer, a high-quality instrument and brought to you by Spectrum Industries. Designed with precision and reliability in mind, this current transformer is an essential tool for accurately measuring electrical current in various industrial and commercial applications. Whether you're conducting maintenance, performing system diagnostics, or monitoring power consumption, the Model 298 offers the performance and durability required to get precise readings in demanding environments.
Overview
Introducing the Model 298 Current Transformer, a high-quality instrument and brought to you by Spectrum Industries. Designed with precision and reliability in mind, this current transformer is an essential tool for accurately measuring electrical current in various industrial and commercial applications. Whether you're conducting maintenance, performing system diagnostics, or monitoring power consumption, the Model 298 offers the performance and durability required to get precise readings in demanding environments.
a global leader in electrical equipment and technology, this current transformer embodies decades of engineering expertise and innovation. Spectrum Industries has carefully selected and integrated the Model 298 into their product lineup to ensure that users receive a dependable and efficient solution for their current measurement needs. Its robust construction and high accuracy make it suitable for use in a wide range of electrical systems, from small-scale installations to large industrial facilities.
The Model 298 Current Transformer features user-friendly operation, making it accessible for both experienced technicians and those new to electrical testing. Its compatibility with various measurement devices and its ability to handle high currents safely make it a versatile choice for professionals seeking precision and reliability. With Spectrum Industries' commitment to quality and our renowned engineering excellence, the Model 298 stands out as a trusted instrument for accurate current measurement.
Request a Quote for Model 298 Current Transformer
Product Specifications
- Frequency
- 50–400 Hz
- Insulation BIL
- 10 kV
- Weight
- 12 lbs
- Application
- Metering, Protection
- Standards
- UL, ANSI/IEEE C57.13, IEC 44-1
- Window Diameter
- 3.00"
- Terminals
- Brass studs No. 8-32 with one flatwasher, lockwasher and regular nut
- Mounting Bracket Kit
- 0221B00259 (ordered separately)
- Multi-Ratio Option
- Multi-ratios available on request
- Industry Canada Approval
- T-203
- Insulation Level
- 600 Volts, 10 kV BIL full wave
Specification Table
| Primary A | Secondary A | Ratio (display) | Relay Class | ANSI Metering Class | Thermal Rating Factor @ 30°C | Thermal Rating Factor @ 55°C | Secondary Resistance |
|---|---|---|---|---|---|---|---|
| 50 | 5 | 50:5 | — | — | 2 | 2 | 0.023 |
| 75 | 5 | 75:5 | — | 1.2B0.2 | 2 | 2 | 0.028 |
| 100 | 5 | 100:5 | C10 | 0.6B0.2 | 2 | 2 | 0.04 |
| 150 | 5 | 150:5 | C10 | 0.6B0.2 | 2 | 2 | 0.06 |
| 200 | 5 | 200:5 | C20 | 0.6B0.5 | 2 | 2 | 0.08 |
| 250 | 5 | 250:5 | C20 | 0.3B0.2 | 2 | 2 | 0.073 |
| 300 | 5 | 300:5 | C20 | 0.3B0.2 | 2 | 2 | 0.087 |
| 400 | 5 | 400:5 | C20 | 0.3B0.9 | 2 | 1.5 | 0.186 |
| 500 | 5 | 500:5 | C50 | 0.3B0.9 | 2 | 1.5 | 0.233 |
| 600 | 5 | 600:5 | C50 | 0.3B1.8 | 1.5 | 1.33 | 0.279 |
| 750 | 5 | 750:5 | C50 | 0.3B1.8 | 1.5 | 1 | 0.349 |
| 800 | 5 | 800:5 | C50 | 0.3B1.8 | 1.5 | 1 | 0.372 |
