Model BL-40 Digital Meter
Introducing the Model BL-40 Digital Meter, a precision instrument and brought to you by Spectrum Industries. Designed to deliver accurate and reliable measurements, this digital meter is an essential tool for professionals and enthusiasts alike who require dependable performance in various testing and measurement applications.
Overview
Introducing the Model BL-40 Digital Meter, a precision instrument and brought to you by Spectrum Industries. Designed to deliver accurate and reliable measurements, this digital meter is an essential tool for professionals and enthusiasts alike who require dependable performance in various testing and measurement applications.
a globally recognized leader in innovative technology and engineering, the Model BL-40 combines advanced features with user-friendly operation. Its robust construction ensures durability and long-term reliability, making it suitable for demanding environments. Whether you are conducting electrical diagnostics, monitoring system performance, or performing detailed measurements, this digital meter offers the precision you need to get the job done efficiently.
Spectrum Industries takes pride in offering high-quality, reliable instrumentation, and the Model BL-40 Digital Meter is no exception. Its intuitive interface and clear digital display make it easy to read measurements quickly, reducing the chance of errors. Additionally, the device’s versatile functionality allows it to be used across a wide range of applications, from industrial maintenance to educational purposes.
Overall, the Model BL-40 Digital Meter by, supplied by Spectrum Industries, is a trusted choice for anyone seeking a dependable and accurate measurement tool. Its combination of advanced technology, durability, and ease of use makes it an invaluable addition to any toolkit.
Request a Quote for Model BL-40 Digital Meter
Product Specifications
- Operating Temperature
- 0°C to 60°C
- Mounting
- Panel mount
- Application
- Metering, Process Control
- Power Supply Option PS1
- 85-265 VAC / 95-370 VDC @ 2.5W max 3.2W
- Power Supply Option PS2
- 15-48 VAC / 10-72 VDC @ 2.5W max 3.2W
- A/D Converter
- 14 bit single slope
- Temperature Coefficient
- 100 ppm/degC typical
- Warm-up Time
- 2 minutes
- Relative Humidity
- 95% non-condensing
- Case Dimensions
- 1/16 DIN Bezel 96x24mm, depth 122.2mm (4.83 in) behind bezel
- Weight
- 7 oz (9 oz packed)
- Excitation
- 24 VDC (external transmitters); 5 or 10 VDC (resistance bridge sensors)
- Setpoints
- 3 programmable setpoints with hysteresis; delay-on-make / delay-on-break for SP1 and SP2
- Programming
- Three-button front-panel (UP, DOWN, PROGRAM)
- Overall Accuracy — Accuracy
- 0.05
- Overall Accuracy — Condition
- of reading + 2 counts
- Response Time — Value
- 200
- Response Time — Condition
- 5 conversions per second typical
- Displayed Parameters — Count
- 4
- Displayed Parameters — Notes
- 4-digit 0.56 inch LED display, range -1999 to 9999 (12000 counts)
- Input Voltage Option — Volts
- 265
- Input Voltage Option — AC/DC
- ACDC
Specification Table
| Kind | Scale Min | Scale Max | Scale Unit | Accuracy |
|---|---|---|---|---|
| AC voltmeter | 0 | 600 | V | 0.05 |
| AC ammeter | 0 | 1 | A | 0.05 |
| AC ammeter | 0 | 5 | A | 0.05 |
| DC voltmeter | 0 | 200 | V | 0.05 |
| DC ammeter | 0 | 5 | A | 0.05 |
| DC ammeter | 0 | 1 | A | 0.05 |
| frequency | 0 | 199.9 | Hz | 0.05 |
Specification Table
| Input Module | Input Range | Scaling | Sensor | Wiring | Range | Sensitivity | Excitation |
|---|---|---|---|---|---|---|---|
| IP01 | 4-20 mA | 0-100.00 | — | — | — | — | — |
| IT03 | — | — | 100 ohm Pt RTD | 2/3/4-wire | -200 to 800 degC | — | — |
| IT07 | — | — | Type-K Thermocouple | — | 0 to 1999 degF | — | — |
| IS05 | — | — | — | 4-wire | — | 20/2 mV/V | 5 or 10 VDC |
| IR05 | — | — | — | — | 2 kohm | — | — |
Process-loop input module configuration for 4-20 mA signals scaled 0-100.00.
