Model BL-40F Digital Meter
Introducing the Model BL-40F Digital Meter, a reliable and precise measurement instrument, now available through Spectrum Industries. Designed with accuracy and ease of use in mind, this digital meter is an essential tool for professionals across various industries who require dependable readings in their daily operations. Whether you're conducting electrical diagnostics, testing circuit parameters, or performing routine maintenance, the Model BL-40F offers the performance and durability needed to get the job done efficiently.
Overview
Introducing the Model BL-40F Digital Meter, a reliable and precise measurement instrument, now available through Spectrum Industries. Designed with accuracy and ease of use in mind, this digital meter is an essential tool for professionals across various industries who require dependable readings in their daily operations. Whether you're conducting electrical diagnostics, testing circuit parameters, or performing routine maintenance, the Model BL-40F offers the performance and durability needed to get the job done efficiently.
a global leader in innovative electrical and electronic solutions, this digital meter embodies the high standards and technological advancements that is known for. Its robust construction ensures longevity and consistent performance even in demanding environments. The user-friendly interface allows for quick setup and straightforward operation, making it suitable for both seasoned technicians and those new to electrical measurement.
Spectrum Industries is proud to distribute this high-quality product, ensuring that customers receive a device that meets rigorous standards of accuracy and reliability. The Model BL-40F Digital Meter combines advanced features with practical design, making it an indispensable tool for electrical testing, troubleshooting, and analysis. Trust in ’s expertise and Spectrum Industries’ commitment to quality to support your measurement needs with this exceptional digital meter.
Request a Quote for Model BL-40F Digital Meter
Product Specifications
- Frequency
- 9999 Hz
- Operating Temperature
- 0°C to 60°C
- Weight
- 0.44 lbs
- Mounting
- Panel mount
- Application
- Metering
- A/D Converter
- 14 bit single slope
- Temperature Coefficient
- 100 ppm/°C (typical)
- Warm-up Time
- 2 minutes
- Conversion Rate
- 5 conversions per second (typical)
- Relative Humidity
- 95% (non-condensing)
- Case Dimensions
- 1/16 DIN, bezel 96x24 mm (3.78" x 0.95"), 122.2 mm depth behind bezel
- Input Frequency Ranges
- 99.99 Hz / 999.9 Hz / 9999 Hz (front-panel selectable)
- Overall Accuracy — Accuracy
- 0.05
- Overall Accuracy — Condition
- of reading + 2 counts
- Displayed Parameters — Count
- 1
- Displayed Parameters — Notes
- 4-digit 0.56" LED display, range -1999 to 9999 counts (12000 counts). Three front-panel selectable ranges; three programmable setpoints; peak/valley view and reset.
Specification Table
| Option Group | Display Color | Digit Height (in) | AC Range | DC Range | Max Power (W) | Input Type | Ranges (Hz) | Output | Max Loop Resistance (Ω) | Resolution (bits) | Min Load Resistance (Ω) | Relay Count | Relay Type | Notes | Relay Types |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Display | Red LED | 0.56 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Display | Super-bright red LED | 0.56 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Display | Green LED | 0.56 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Power Supply | — | — | 85-265 VAC | 95-370 VDC | 3.2 | — | — | — | — | — | — | — | — | — | — |
| Power Supply | — | — | 15-48 VAC | 10-72 VDC | 3.2 | — | — | — | — | — | — | — | — | — | — |
| Input Module | — | — | — | — | — | Frequency with 24V excitation | 99.99 / 999.9 / 9999 | — | — | — | — | — | — | — | — |
| Input Module | — | — | — | — | — | Line frequency | — | — | — | — | — | — | — | — | — |
| Analog Output | — | — | — | — | — | — | — | 4-20 mA isolated | 500 | 16 | — | — | — | — | — |
| Analog Output | — | — | — | — | — | — | — | 0-10 VDC isolated | — | 16 | 500 | — | — | — | — |
| Relay Output | — | — | — | — | — | — | — | — | — | — | — | 1 | 5 A Form A | — | — |
| Relay Output | — | — | — | — | — | — | — | — | — | — | — | 2 | 5 A Form A | — | — |
| Relay Output | — | — | — | — | — | — | — | — | — | — | — | 3 | 5 A Form A | SP1 and SP2 common | — |
| Relay Output | — | — | — | — | — | — | — | — | — | — | — | 1 | 10 A Form C | — | — |
| Relay Output | — | — | — | — | — | — | — | — | — | — | — | 2 | — | — | 1x 10 A Form C + 1x 5 A Form A |
Standard 4-digit 0.56" red LED display.
