Model BL-40PSF Digital Meter
Introducing the Model BL-40PSF Digital Meter, a state-of-the-art measurement solution, brought to you by Spectrum Industries. Designed with precision and reliability in mind, this digital meter offers accurate readings for a variety of industrial and commercial applications. Whether you're monitoring electrical parameters or conducting detailed diagnostics, the BL-40PSF provides the performance and durability you need to get the job done efficiently.
Overview
Introducing the Model BL-40PSF Digital Meter, a state-of-the-art measurement solution, brought to you by Spectrum Industries. Designed with precision and reliability in mind, this digital meter offers accurate readings for a variety of industrial and commercial applications. Whether you're monitoring electrical parameters or conducting detailed diagnostics, the BL-40PSF provides the performance and durability you need to get the job done efficiently.
a globally recognized leader in technology and innovation, this digital meter benefits from decades of expertise in electrical measurement and instrumentation. Spectrum Industries has partnered with to deliver a high-quality product that combines advanced features with user-friendly operation. The BL-40PSF is built to withstand demanding environments, ensuring consistent accuracy over time and providing confidence in your measurements.
With its intuitive interface and robust construction, the Model BL-40PSF is suitable for professionals across various industries, including manufacturing, maintenance, and research. Its precise digital display allows for easy reading and quick data collection, making it an invaluable tool for technicians and engineers alike. Trust in the legacy of ’s engineering excellence and Spectrum Industries’ commitment to quality—choose the Model BL-40PSF Digital Meter for your measurement needs.
Request a Quote for Model BL-40PSF Digital Meter
Product Specifications
- Operating Temperature
- 0°C to 60°C
- Weight
- 0.44 lbs
- Mounting
- Panel mount
- Application
- Metering, Process Control
- Power Supply PS1
- 85-265 VAC / 95-370 VDC @ 2.5W max 3.2W
- Power Supply PS2
- 15-48 VAC / 10-72 VDC @ 2.5W max 3.2W
- A/D Converter
- 14 bit single slope
- Temperature Coefficient
- 100 ppm/°C typical
- Warm-up Time
- 2 minutes
- Conversion Rate
- 5 conversions per second typical
- Display
- 4-digit 0.56" Red LED (std); Green or Super Bright Red optional; range -1999 to 9999 (12000 counts)
- Relay Output
- Three 5 A Form A relays, or one 10 A Form C plus one 5 A Form A
- Analog Output
- Isolated 16-bit user scalable mA or V (OIC: 4-20 mA @ 0-500 Ω max; OIV: 0-10 V DC @ 500 Ω or higher)
- Excitation Supply
- 24 V DC for external transmitters; 5 or 10 V DC for resistance bridge sensors
- Relative Humidity
- 95% non-condensing
- Case
- 1/16 DIN bezel 96 x 24 mm; depth behind bezel 122.2 mm (4.83") plus 12.7 mm (0.5") for right-angled connectors
- Setpoints
- Three programmable setpoints with HI/LO activation, hysteresis, and make/break delays on SP1 and SP2
- Input Compatibility
- More than 38 plug-in I-Series input signal conditioners (AC/DC current, AC/DC voltage, load cell, 4-20 mA, pressure, process, resistance, prototype, temperature)
- Overall Accuracy — Accuracy
- 0.05
- Overall Accuracy — Condition
- of reading + 2 counts
- Auxiliary Voltage Option — Volts
- 120
- Auxiliary Voltage Option — AC/DC
- ACDC
