Model BL-40RPM Digital Meter
Introducing the Model BL-40RPM Digital Meter, a precision instrument and brought to you by Spectrum Industries. Designed to provide accurate and reliable rotational speed measurements, this digital meter is an essential tool for professionals across various industries, including manufacturing, engineering, and maintenance. Its user-friendly interface and advanced features make it an ideal choice for those seeking a dependable and straightforward solution to monitor and analyze rotational speeds.
Overview
Introducing the Model BL-40RPM Digital Meter, a precision instrument and brought to you by Spectrum Industries. Designed to provide accurate and reliable rotational speed measurements, this digital meter is an essential tool for professionals across various industries, including manufacturing, engineering, and maintenance. Its user-friendly interface and advanced features make it an ideal choice for those seeking a dependable and straightforward solution to monitor and analyze rotational speeds.
a globally recognized leader in technological innovation and quality, the Model BL-40RPM Digital Meter exemplifies the company's commitment to delivering high-performance measurement devices. Spectrum Industries, known for its dedication to providing top-tier industrial equipment, ensures that this digital meter meets rigorous standards for precision and durability. Whether used in laboratory settings or on the factory floor, this device offers consistent performance and ease of use, making it a valuable addition to any technical toolkit.
The Model BL-40RPM Digital Meter boasts a clear digital display, allowing for quick and easy reading of rotational speeds. Its compact design ensures portability and convenience, while its robust construction guarantees long-term reliability even in demanding environments. With features tailored to enhance measurement accuracy and operational efficiency, this digital meter and Spectrum Industries is designed to meet the needs of professionals who require dependable speed monitoring with minimal hassle.
Request a Quote for Model BL-40RPM Digital Meter
Product Specifications
- Operating Temperature
- 0°C to 60°C
- Weight
- 0.44 lbs
- Mounting
- Panel mount
- Application
- Metering
- A/D Converter
- 14 bit single slope
- Accuracy
- 2 count
- Temperature Coefficient
- 100 ppm/degC (Typical)
- Warm-up Time
- 2 minutes
- Conversion Rate
- 5 conversions per second (Typical)
- Relative Humidity
- 95% (non condensing)
- Case Dimensions
- 1/16 DIN Bezel 96x24mm; depth behind bezel 122.2 mm (4.83 in), plus 12.7 mm (0.5 in) for right-angled connectors
- Power Supply PS1
- 85-265 VAC / 95-370 VDC @ 2.5W max 3.2W
- Power Supply PS2
- 15-48 VAC / 10-72 VDC @ 2.5W max 3.2W
- Relay Output
- Three 5A Form A relays, or one 10A Form C plus one 5A Form A
- Display Options
- Red LED (standard), optional Green or Super Bright Red; 0.56 inch high, 4-digit, range 0-9999
- Displayed Parameters — Count
- 1
- Displayed Parameters — Notes
- 4-digit 0.56 inch LED, range 0 to 9999 counts; RPM measurement with 0.1, 1, and 10 RPM resolutions (99.99 x 1000 RPM max)
- Auxiliary Voltage Option — Volts
- 24
- Auxiliary Voltage Option — AC/DC
- DC
Specification Table
| Display | Power Supply | Input Module | Analog Output | Relay Output |
|---|---|---|---|---|
| Red LED 0.56 in | 85-265 VAC / 95-370 VDC | IF05 Universal Frequency/RPM | None | Single 5A Form A |
| Super-bright Red LED 0.56 in | 85-265 VAC / 95-370 VDC | IF05 | None | Single 5A Form A |
| Green LED 0.56 in | 85-265 VAC / 95-370 VDC | IF05 | None | Single 5A Form A |
| Red LED 0.56 in | 15-48 VAC / 10-72 VDC | IF05 | None | Single 5A Form A |
| Red LED 0.56 in | 85-265 VAC / 95-370 VDC | IF05 | Isolated 4-20 mA (500 ohm max loop) | Single 5A Form A |
| Red LED 0.56 in | 85-265 VAC / 95-370 VDC | IF05 | Isolated 0-10 VDC (500 ohm or higher) | Single 5A Form A |
| Red LED 0.56 in | 85-265 VAC / 95-370 VDC | IF05 | None | Dual 5A Form A |
| Red LED 0.56 in | 85-265 VAC / 95-370 VDC | IF05 | None | Three 5A Form A (SP1/SP2 common) |
| Red LED 0.56 in | 85-265 VAC / 95-370 VDC | IF05 | None | Single 10A Form C |
| Red LED 0.56 in | 85-265 VAC / 95-370 VDC | IF05 | None | Single 10A Form C + Single 5A Form A |
Base configuration: red LED display, standard wide-range AC/DC power supply, universal frequency/RPM input module, single 5A Form A relay
