Model JCD-5 Outdoor Current Transformer - 15kV Class
Introducing the Model JCD-5 Outdoor Current Transformer, a high-quality solution designed to meet the demanding needs of electrical measurement and distribution systems. and produced exclusively by Spectrum Industries, this current transformer exemplifies precision, durability, and reliability in outdoor electrical applications. Engineered to operate efficiently in various environmental conditions, the Model JCD-5 is ideal for utility companies, industrial facilities, and electrical contractors seeking a dependable component for their metering and protection systems.
Overview
Introducing the Model JCD-5 Outdoor Current Transformer, a high-quality solution designed to meet the demanding needs of electrical measurement and distribution systems. and produced exclusively by Spectrum Industries, this current transformer exemplifies precision, durability, and reliability in outdoor electrical applications. Engineered to operate efficiently in various environmental conditions, the Model JCD-5 is ideal for utility companies, industrial facilities, and electrical contractors seeking a dependable component for their metering and protection systems.
Built with robust construction and advanced materials, the Model JCD-5 offers excellent performance at a 15kV class rating, ensuring accurate current measurement and system protection. Its outdoor design features weather-resistant components, allowing it to withstand harsh elements such as rain, wind, and temperature fluctuations without compromising functionality. The product’s compact form factor and easy installation make it a versatile choice for a wide range of electrical setups, simplifying maintenance and reducing downtime.
a global leader in electrical equipment manufacturing, the Model JCD-5 benefits from decades of engineering expertise and innovation. Spectrum Industries ensures that each transformer adheres to rigorous quality standards, providing customers with a reliable and long-lasting product. Whether for new installations or upgrades to existing infrastructure, the Model JCD-5 outdoor current transformer is a trusted choice for ensuring safe and accurate electrical system operation.
Request a Quote for Model JCD-5 Outdoor Current Transformer - 15kV Class
Product Specifications
- Frequency
- 50–60 Hz
- Insulation BIL
- 110 kV
- Weight
- 135 lbs
- Mounting
- Outdoor
- Application
- Metering, Protection
- Rated Voltage
- 15,000 V
- Window Diameter
- 5.56 in
- Primary Current Range
- 1,200 A to 4,000 A
- ANSI Meter Accuracy Class
- 0.3 at B-0.1 through B-1
- Accuracy Class
- 0.15 accuracy class available
- Shipping / Net Weight
- 150 / 135 lbs
- Revenue Metering Approval
- Measurement Canada AE-0840 or AE-1447
Specification Table
| Primary A | Secondary A | Ratio (display) | Relay Class | ANSI Metering Class | Thermal Rating Factor @ 30°C |
|---|---|---|---|---|---|
| 1200 | 5 | 1200:5 | C200 | 0.3B0.9 | 1.33 |
| 1500 | 5 | 1500:5 | C200 | 0.3B0.9 | 1.33 |
| 2000 | 5 | 2000:5 | C400 | 0.3B0.9 | 1.33 |
| 3000 | 5 | 3000:5 | C400 | 0.3B0.9 | 1.33 |
| 4000 | 5 | 4000:5 | C200 | 0.3B0.9 | 1.33 |
| 1200 | 5 | 600/1200:5 | C100 | 0.3B0.9 | 2 |
| 1500 | 5 | 750/1500:5 | C100 | 0.3B0.9 | 2 |
| 2000 | 5 | 1000/2000:5 | C200 | 0.3B0.9 | 2 |
| 3000 | 5 | 1500/3000:5 | C200 | 0.3B0.9 | 2 |
| 4000 | 5 | 2000/4000:5 | C100 | 0.3B0.9 | 2 |
