Type G - Switchboard Shunts Without Base
Introducing the Type G Switchboard Shunts Without Base, a reliable and efficient solution designed to meet the demanding needs of modern electrical systems. Crafted with precision and high-quality materials, these shunts are essential components for accurate current measurement and protection in switchboards. Their robust construction ensures durability and consistent performance, even in challenging industrial environments.
Overview
Introducing the Type G Switchboard Shunts Without Base, a reliable and efficient solution designed to meet the demanding needs of modern electrical systems. Crafted with precision and high-quality materials, these shunts are essential components for accurate current measurement and protection in switchboards. Their robust construction ensures durability and consistent performance, even in challenging industrial environments.
The absence of a base in this model offers flexibility in installation, allowing for seamless integration into various switchboard configurations. This design feature simplifies maintenance and installation processes, reducing downtime and enhancing overall system efficiency. The Type G Switchboard Shunts are engineered to provide precise current readings, which are crucial for effective monitoring and control of electrical circuits. Their compatibility with a wide range of switchboard setups makes them a versatile choice for electrical engineers and technicians alike.
Furthermore, these shunts are designed to meet stringent safety standards, ensuring reliable operation without compromising safety. Whether used in new installations or as replacements in existing systems, the Type G Switchboard Shunts Without Base deliver dependable performance, supporting the safe and efficient operation of electrical infrastructure. Invest in these high-quality shunts to enhance your switchboard's accuracy, reliability, and ease of maintenance.
Request a Quote for Type G - Switchboard Shunts Without Base
Product Specifications
- Application
- Metering
- Millivolt Rating
- 50 mV or 100 mV
- Hole Diameter Tolerance
- ± 0.015 in
- Overall Accuracy — Accuracy
- 0.25
- Overall Accuracy — Condition
- Standard accuracy
Specification Table
| Max Current | mV Output @ rated | Tolerance |
|---|---|---|
| 75 | 50 | 0.25 |
| 80 | 50 | 0.25 |
| 100 | 50 | 0.25 |
| 150 | 50 | 0.25 |
| 200 | 50 | 0.25 |
| 250 | 50 | 0.25 |
| 300 | 50 | 0.25 |
| 400 | 50 | 0.25 |
| 500 | 50 | 0.25 |
| 600 | 50 | 0.25 |
| 800 | 50 | 0.25 |
| 1000 | 50 | 0.25 |
| 1200 | 50 | 0.25 |
| 75 | 100 | 0.25 |
| 80 | 100 | 0.25 |
| 100 | 100 | 0.25 |
| 150 | 100 | 0.25 |
| 200 | 100 | 0.25 |
| 250 | 100 | 0.25 |
| 300 | 100 | 0.25 |
| 400 | 100 | 0.25 |
| 500 | 100 | 0.25 |
| 600 | 100 | 0.25 |
| 800 | 100 | 0.25 |
| 1000 | 100 | 0.25 |
| 1200 | 100 | 0.25 |
| 1500 | 50 | 0.25 |
| 2000 | 50 | 0.25 |
| 2500 | 50 | 0.25 |
| 1500 | 100 | 0.25 |
| 2000 | 100 | 0.25 |
| 2500 | 100 | 0.25 |
