Type H - Multi-Fin Design Bus - Bar Shunts
Overview
The Type H Multi-Fin Design Bus Bar Shunts offered by Spectrum are engineered to deliver precise and reliable current measurement for a wide range of electrical applications. Designed with innovation and durability in mind, these shunts feature a unique multi-fin structure that ensures optimal heat dissipation and improved performance under high current loads. Whether used in industrial, commercial, or renewable energy systems, the Type H shunts provide accurate, real-time current readings essential for system monitoring and protection.
Constructed from high-quality materials, these bus bar shunts are built to withstand harsh operating environments, offering long-term stability and minimal maintenance. Their robust design not only ensures dependable operation but also simplifies installation, making them an ideal choice for engineers and technicians seeking efficiency and reliability. The multi-fin configuration enhances the surface area for heat transfer, allowing the shunt to handle larger currents without overheating, thereby increasing safety and operational lifespan.
Furthermore, the Type H Multi-Fin Design Bus Bar Shunts are compatible with various measurement and control systems, facilitating seamless integration into existing electrical infrastructure. Their precise measurement capabilities support effective load management, fault detection, and system optimization. Overall, these shunts represent a high-performance solution for accurate current measurement, combining innovative design with durability to meet the demanding needs of modern electrical systems.
Request a Quote for Type H - Multi-Fin Design Bus - Bar Shunts
Product Specifications
- Application
- Metering
- Product Type
- DC Ammeter Shunt - Multi-Fin Design
- Overall Accuracy — Accuracy
- 0.25
- Overall Accuracy — Condition
- standard
Specification Table
| Max Current | mV Output @ rated | Tolerance |
|---|---|---|
| 2500 | 50 | 0.25 |
| 3000 | 50 | 0.25 |
| 4000 | 50 | 0.25 |
| 4500 | 50 | 0.25 |
| 5000 | 50 | 0.25 |
| 6000 | 50 | 0.25 |
| 7000 | 50 | 0.25 |
| 7500 | 50 | 0.25 |
| 8000 | 50 | 0.25 |
| 9000 | 50 | 0.25 |
| 10000 | 50 | 0.25 |
| 12000 | 50 | 0.25 |
| 15000 | 50 | 0.25 |
| 18000 | 50 | 0.25 |
| 20000 | 50 | 0.25 |
| 25000 | 50 | 0.25 |
| 30000 | 50 | 0.25 |
| 2500 | 100 | 0.25 |
| 3000 | 100 | 0.25 |
| 4000 | 100 | 0.25 |
| 4500 | 100 | 0.25 |
| 5000 | 100 | 0.25 |
| 6000 | 100 | 0.25 |
| 7000 | 100 | 0.25 |
| 7500 | 100 | 0.25 |
| 8000 | 100 | 0.25 |
| 9000 | 100 | 0.25 |
| 10000 | 100 | 0.25 |
| 12000 | 100 | 0.25 |
| 15000 | 100 | 0.25 |
| 18000 | 100 | 0.25 |
| 20000 | 100 | 0.25 |
| 25000 | 100 | 0.25 |
| 30000 | 100 | 0.25 |
