Type PCS - Printed Circuit Board and Adjustable Shunts
Introducing the Type PCS Printed Circuit Board and Adjustable Shunts, a versatile and reliable solution designed to meet the demanding needs of modern electrical and electronic applications. Crafted with precision and high-quality materials, this product offers exceptional performance in current measurement and circuit management. Its robust construction ensures durability and long-term stability, making it an ideal choice for both industrial and DIY projects.
Overview
Introducing the Type PCS Printed Circuit Board and Adjustable Shunts, a versatile and reliable solution designed to meet the demanding needs of modern electrical and electronic applications. Crafted with precision and high-quality materials, this product offers exceptional performance in current measurement and circuit management. Its robust construction ensures durability and long-term stability, making it an ideal choice for both industrial and DIY projects.
The Type PCS PCB is engineered to provide accurate and consistent readings, thanks to its carefully designed layout and adjustable shunt feature. The adjustable shunts allow users to calibrate and fine-tune current measurements, ensuring precise control and monitoring of electrical systems. This flexibility makes it suitable for a wide range of applications, from testing and development to maintenance and troubleshooting.
Furthermore, the product's compact and user-friendly design simplifies integration into existing systems. Its standardized form factor and clear labeling facilitate quick installation and easy adjustments, saving valuable time and effort. Whether you're working on complex circuit designs or simple electrical setups, the Type PCS Printed Circuit Board and Adjustable Shunts deliver dependable performance and adaptability.
Overall, this product stands out as a reliable, customizable, and efficient tool for professionals and hobbyists alike, helping you achieve accurate electrical measurements and optimal circuit operation with confidence.
Request a Quote for Type PCS - Printed Circuit Board and Adjustable Shunts
Product Specifications
- Standards
- RoHS
- Temperature Coefficient of Resistance (TCR)
- ±15 ppm/°C
- Meter Connections
- Tinned copper wire, 18 AWG (0.040")
- Current Connections
- Tinned with 'Tinsil', approx. 0.003" thick in shaded areas
- Output Voltage
- 50 mV
- Overall Accuracy — Accuracy
- 0.25
- Overall Accuracy — Condition
- Standard accuracy; ±0.1% available as maximum accuracy option
Specification Table
| Max Current | mV Output @ rated | Tolerance |
|---|---|---|
| 10 | 50 | 0.25 |
| 15 | 50 | 0.25 |
| 20 | 50 | 0.25 |
| 25 | 50 | 0.25 |
| 30 | 50 | 0.25 |
| 40 | 50 | 0.25 |
| 50 | 50 | 0.25 |
| 60 | 50 | 0.25 |
| 75 | 50 | 0.25 |
