Model 193 Current Transformer
Introducing the Model 193 Current Transformer, a reliable and precise solution, now available through Spectrum Industries. This high-quality current transformer is engineered to deliver accurate current measurement and monitoring in a variety of electrical systems, ensuring optimal performance and safety. Whether used in industrial, commercial, or utility applications, the Model 193 provides consistent and dependable readings that are essential for effective system management.
Overview
Introducing the Model 193 Current Transformer, a reliable and precise solution, now available through Spectrum Industries. This high-quality current transformer is engineered to deliver accurate current measurement and monitoring in a variety of electrical systems, ensuring optimal performance and safety. Whether used in industrial, commercial, or utility applications, the Model 193 provides consistent and dependable readings that are essential for effective system management.
a global leader in electrical and electronic manufacturing, this current transformer benefits from decades of innovation and expertise. Its robust construction and advanced design make it suitable for demanding environments, offering durability and long-term stability. The Model 193 is engineered to meet stringent industry standards, providing users with confidence in its performance and reliability. Its compact form factor allows for easy installation in existing systems, making it a versatile choice for a wide range of applications.
Spectrum Industries is proud to distribute this high-quality product, ensuring that customers receive a device that combines ’s technological excellence with Spectrum’s commitment to customer satisfaction. Whether you're upgrading existing equipment or designing new electrical systems, the Model 193 Current Transformer is an excellent choice for accurate, dependable current measurement. Trust in ’s legacy of quality and Spectrum Industries’ dedication to service to meet your electrical measurement needs.
Request a Quote for Model 193 Current Transformer
Product Specifications
- Frequency
- 50–400 Hz
- Insulation BIL
- 10 kV
- Weight
- 4.25 lbs
- Application
- Metering, Protection
- Standards
- UL, ANSI/IEEE C57.13, IEC 44-1
- Window Diameter
- 2.13 in
- Insulation Voltage Rating
- 600 V
- Terminal Type
- Brass stud No. 8-32 with one flatwasher, lockwasher, and regular nut
- Mounting Bracket
- Optional bracket kit 0221B00777, ordered separately
- Multi-ratio Availability
- Multi-ratios available on request
Specification Table
| Primary A | Secondary A | Ratio (display) | Relay Class | ANSI Metering Class | Thermal Rating Factor @ 30°C | Thermal Rating Factor @ 55°C | Secondary Resistance |
|---|---|---|---|---|---|---|---|
| 100 | 5 | 100:5 | — | 1.2B0.2 | 2 | 2 | 0.024 |
| 150 | 5 | 150:5 | — | 0.6B0.2 | 2 | 2 | 0.038 |
| 200 | 5 | 200:5 | — | 0.3B0.2 | 2 | 2 | 0.071 |
| 250 | 5 | 250:5 | C10 | 0.3B0.2 | 2 | 1.5 | 0.072 |
| 300 | 5 | 300:5 | C10 | 0.3B0.5 | 2 | 1.5 | 0.082 |
| 400 | 5 | 400:5 | C10 | 0.3B0.9 | 1.5 | 1.33 | 0.142 |
| 500 | 5 | 500:5 | C20 | 0.3B0.9 | 1.5 | 1.33 | 0.159 |
| 600 | 5 | 600:5 | C20 | 0.3B0.9 | 1.5 | 1 | 0.191 |
